1. Unplug the switch.
2. While holding the Mode button on the left side of front panel , reconnect power.
3. When the LED above Port 1x goes out, release the Mode button.
4. Issue the flash_init command:
switch: flash_init
Initializing flash..

5. Issue the load_helper command:
switch: load_helper
switch:

Catalyst 3500 Xl Manual

6. Rename the configuration file:
switch: rename flash:config.text flash:config.old
7. Boot the switch using the boot command:
switch: boot
Loading 'flash:c3550-i9q3l2-mz..EA1c.bin'..########

Would you like to enter the initial configuration dialog? [yes/no]

8. Select 'yes' when you are ready to configure the switch or 'no' to start without configuration wizard. You're done.

Cisco 3500 XL Series – a scalable line of 10/100 and Gigabit ethernet switches. It’s a low cost, high performance switching solution.

  • Low cost, high performance switching
  • Stackable switching
  • High speed stacking bus preserves desktop ports
  • Up to 16 interconnected 3500 XL, 2900 XL and 1900 Series switches

Cisco 3500 XL Series is comprised of the following switches:

Catalyst 3508G XL, Catalyst 3512 XL, Catalyst 3524 XL, WS-C3524PWR-XL-EN, Catalyst 3548 XL

Catalyst 3500 Xl Manual

In order to illustrate the differences between these switches, we’ve provided a table to show you the basics.

ModelGig / Fast EthernetLayerStandalone / StackablePoEFixed PortsGBIC/SFPBackplaneEOL / EOS
WS-C3508G-XL-ENGig3StandaloneGBIC, 810.8 GbpsYes (7/27/02)
WS-C3512-XL-ENFE3Standalone

Fixed 10/100,

12 RJ45

GBIC, 210.8 GbpsYes (7/27/02)
WS-C3524PWR-XL-ENFE3StandaloneCisco

Fixed 10/100, Word prediction software free.

24 RJ45

GBIC, 210.8 GbpsYes (8/12/03)
WS-C3524-XL-ENFE3Standalone

Fixed 10/100,

24 RJ45
GBIC, 210.8 GbpsYes (7/27/02)
WS-C3548-XL-ENFE3Standalone

Fixed 10/100,

48 RJ45
GBIC, 210.8 GbpsYes (7/27/02)
